Custom 3.5" IPS TFT LCD Display Module for Solar Controller
Time：2025-12-03
Overview

In this project, a client who was developing next-generation solar controllers needed a small display module that could be read in sunlight and had touchscreen functionality. Sonytek provided the TT03503CTA-50, a 3.5-inch 320x480 IPS TFT LCD paired with a capacitive touch panel driven by the FT6366U controller. This makes it easy to see, reliable and easy to use outside.

Although this model is similar to the well-known ER-TFT035IPS-6 structure, the final product was adjusted to meet the customer's specific mechanical layout and system requirements.

Customer Requirements

The client needed a display solution for a compact solar controller with the following expectations:

Clear outdoor visibility under strong sunlight

Wide viewing angles for different installation positions

Stable touch response even when used with dusty or humid environments

Long-term durability suitable for 24/7 outdoor operation

Compatibility with their existing mainboard and mechanical housing

Sonytek collaborated closely with the client to ensure the module fit both electrical and structural constraints without requiring major system redesign.


Why TT03503CTA-50 Was Selected

1. IPS Technology for Superior Readability

The IPS LCD panel offers:

80° wide viewing angles

Consistent color performance

Better visibility in bright outdoor environments

These features make it ideal for solar controllers where users frequently check parameters in direct sunlight.

2. 320×480 High-Resolution Interface

The crisp resolution ensures:

Clear reading of voltage/current data

Smooth graphical UI

Better user interaction with real-time monitoring screens

3. FT6366U Capacitive Touch Controller

The integrated CTP driven by FT6366U provides:

Fast touch response

Stable performance under outdoor temperature fluctuations

Noise immunity for power-electronics environments

Support for gestures and multi-touch functions

4. Robust Structure for Outdoor Use

The module maintains:

Strong bonding between LCD & touch panel

Reliable FPC connection

Operating temperature suitable for outdoor solar controllers

Customization Highlights

To align with the customer’s hardware and mechanical design, Sonytek delivered several tailored adjustments:

✔ Customized FPC Shape & Length

Optimized to match the customer's PCB connector position, eliminating the need to redesign the housing.

✔ Touch Sensitivity Tuning

FT6366U parameters were adjusted to ensure accurate touch detection even in dusty outdoor scenarios.

✔ Brightness Optimization

The backlight brightness was calibrated for outdoor readability while balancing power efficiency—important for solar-powered equipment.

✔ Mechanical Reinforcement

Extra structural support was added to enhance vibration resistance, critical for field-installed controllers.

Application in Solar Controller Systems

When integrated into the client’s solar controller:

The IPS display improved outdoor legibility of system parameters

The CTP panel made navigation more intuitive

Real-time monitoring (battery SOC, PV input, charging status) became more user-friendly

The compact module fit seamlessly into the existing enclosure

Users can now adjust settings, check statistics, and oversee charging performance with ease.

Project Outcome

After testing and validation, the customized TT03503CTA-50 module successfully entered the client’s production line. The final results included:

Faster UI interaction thanks to FT6366U

Reduced glare issues compared to their previous TN display

Higher customer satisfaction from clear daytime readability

Improved system reliability due to Sonytek’s component durability

This project demonstrates how a standard model—similar to ER-TFT035IPS-6—can be elevated through precise customization to meet a specific industry application.

Looking for a Custom LCD Module?

Sonytek provides custom TFT LCD, touch panel, and display module solutions for industrial, solar energy, IoT, and embedded devices.
If you need FPC customization, brightness tuning, CTP optimization, or mechanical adjustments, feel free to contact us.
